Features and advantages
1. Using Taiwan and Japan servo motor servo motors to control bag making length in high precision, and using Taiwan and Japan inverter to allow AC motor and heater to achieve high efficiency and low power consumption.
2. PLC and touch screen control, lead to intuitive display and convenient operation. If any failure occur, the touch screen will indicate the failure on which part of machine.
3. Using smart temperature control system, when the temperature difference exceeds 10°, it will stop automatically.
4. Also suitable for bag making with various of compostable and bio-degradable films. It has practical and effective designs from the film tension control, bottom seal heating fastness, and smoothly needle pulling-out at rewinding and so on.
5. In order to solve the problem that the bottom seal is not firm enough on heavy duty packaging bags, the machine is using non-stretch design to ensure the firmness of bag making for each large-size bag.
6. It also has a heavy duty model, which is specially designed for making large size and super thick bags.
Technical Parameters
| Model | LQD-500×2 | LQD-700×2 | LQD-900×2 |
| Finished roll width | 100-500mm | 100-700mm | 100-900mm |
| Bag making length | 100-1200mm | ||
| Bag making speed | 20-120 pcs/minx2 | ||
| Bag making Thickness | 0.006-0.2mm | ||
| Applicable Material | HDPE, LDPE, LLDPE, PP, OPP, Compostable, Bio-degradable | ||
| Total Power | 5kw | 6kw | 8kw |
| Dimension | 3800x1100x1580mm | 3800x1300x1580mm | 3800x1500x1580mm |
| Bag making type | Bottom seal single flat bag vest bag | ||
| Final product | Heavy duty packaging bag,industrial packaging bag,dust bag | ||
| Optional Device | Barcode printer,and QR code printer | ||
