LQBUD-65&70&80 blow molding machine

Short Description:

This blow molding machine is suitable for the production of 200ml-10L plastic hollow products,the use of curved elbow lock system,low energy consumption,the center of the lock,the lock force,speed faster,run more smoothly.



Termsof Payment:
30% deposit by T/T when confirming the order,70% balance by T/T before shipping.Or irrevocable L/C at sight
Installation and Training
The price includes the fee of installation, Training and interpreter, However,the relative cost such as international return air tickets between China and Buyer’s country, local transportation, accommodation (3 star hotel), and the pocket money per person for engineers and interpreter will be born by buyer. Or, the customer can find capable interpreter in local. If during Covid19, will do online or video support by whatsapp or wechat software.
Warranty:12 months after B/L date
It is ideal equipment of plastic industry.  More convenient and easy to do adjustment, save labours and cost to support our customers do more effierency.


Product Detail

Product Tags

Product Description

  • 1. This blow molding machine is suitable for the production of 200ml-10L plastic hollow products,the use of curved elbow lock system,low energy consumption,the center of the lock,the lock force,speed faster,run more smoothly.
  • 2. Die opening and closing system:specially designed for Heng lock mould mechanism using a high pressure mode locking,locking plate stress in the centre of the template,clamping force,open the rigid lock template,even if the ultra wide die is also fitted.
  • 3. Die head system:all the use of 38CRMOALA and other materials,the precision machining and heat treatment.
  • 4. Hydraulic system:full hydraulic double proportional hydraulic control ,equipped with imported famous brand hydraulic valve and oil pump,stable,reliable.
  • 5. Automatic flying side device:in addition to the overflow device can accurately remove the product of the residual material,and with a straight push type in addition to the overflow device and a rotary knife type in addition to overflow device, the real realization automatic equipment without manual operation.

Specification

Specification   SLBU-65 SLBU-80
Material   PE,PP,EVA,ABS,PS… PE,PP,EVA,ABS,PS…
Max container capacity L 5 10
Number of die Set 1,2,3,4,6,8 1,2,3,4,6,8
Output(dry cycle) pc/hr 1000*2 950*2
Machine Dimension(LxWxH) M 4000*2300*2200 4600*2600*2600
Total weight Ton 6.5T 7.5T

Clamping Unit
Clamping force KN 65 86
Platen opening stroke MM 220-520 300-600
Platen size(WxH) MM 400*430 450*450
Max mould size(WxH) MM 460*430 500*450
Mold thickness MM 255-280 305-400

Extruder unit
Screw diameter MM 65 80
Screw L/D ratio L/D 25 25
Melting capacity KG/HR 70 120
Number of heating zone KW 15 20
Extruder heating power Zone 3 3
Extruder driving power KW 15 30

Die head
Number of heating zone Zone 2-5 2-5
Power of die heating KW 6 6
Center distance of double die MM 130 160
Center distance of tri-die MM 110 110
Center distance of tetra-die MM 100 100
Center distance of six-die MM 80 80
Max die-pin diameter MM 180 260

Power
Max drive KW 18 35
Total power KW 50 82
Fan power for screw KW 2.4 3.2
Air pressure Mpa 0.6 0.6
Air consumption m³/min 0.4 0.5
Average energy consumption KW 18 22
